E8331L1_WG Schneider electric AvatarOn, switch, 16AX, 250V, 1 way, Wine Gold
E8331L1_WG Schneider electric AvatarOn, switch, 16AX, 250V, 1 way, Wine Gold
Old Price: AED 25
New Price: AED 20 (20%)
AvatarOn, switch, 16AX, 250V, 1 way, Wine Gold
Schneider Electric AvatarOn switch E8331L1_WG is a complete product in color wine gold with 1 rocker. This is a 1-pole 1-way switch. And its rated current is 16AX. It is 86 mm in width, 86 mm in height, 34.2 mm in depth, Its matching mounting box can be recessed into the surface of the wall with flush type. It reaches IP20 degree of protection too. The connection terminals of this switch are brass terminal. Being made of polycarbonate, polycarbonate + GF 20 % material, this switch is quite reliable and resistant. And it is mercury free AvatarOn offers six fashionable, classic appearances, letting your home's details change, just like the changes in your colorful life. Unique, patented technology and exquisite manufacturing ensure comfortable operation, and the easy-mount design allows you to change the faceplates as quickly and easily as you wish.
| Product or component type | Switch |
|---|---|
| Device application | Control |
| load type | Incandescent lamp Resistive Fluorescent lamp Inductive |
| Colour tint | Wine gold |
| Colour tint | Wine gold |
| Device presentation | Complete product |
|---|---|
| Rated current | 16 AX at 250 V AC 50/60 Hz |
| Switch function | 1-pole 1-way |
| Number of gangs | 1 gang |
| Number of rocker | 1 |
| Clamping connection capacity | 3 x 2.5 mm² for solid cable(s) 3 x 2.5 mm² for stranded cable(s) 4 x 1.5 mm² for solid cable(s) 4 x 1.5 mm² for stranded cable(s) |
| Connections - terminals | Brass terminal |
| Material | Polycarbonate: grid plate Polycarbonate: base Polycarbonate: dolly Polycarbonate: frame Polycarbonate + GF 20 %: actuator |
| Device mounting | Flush Surface |
| Width | 86 mm |
| Height | 86 mm |
| Depth | 34.2 mm |
| IP degree of protection | IP20 |
|---|---|
| Maximum ambient air temperature for operation | 45 °C |
| Operating altitude | 2000 m |
| Relative humidity | 0…95 % |
| Standards | MS IEC 60669-1 SS 227-1 IEC 60669-1 BS EN 60669-1 |
| Environmental characteristic | UV resistant |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.4 cm |
| Package 1 Width | 8.6 cm |
| Package 1 Length | 8.6 cm |
| Package 1 Weight | 81.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 60 |
| Package 2 Height | 21.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 39.5 cm |
| Package 2 Weight | 5.634 kg |
